Specifications
|
|
Cable Types
|
Shielded and unshielded Twisted Pair (STP, FTP, SSTP and UTP) LAN cabling:
|
|
Standard Link Interface Adapters
|
- TIA Category 3, 4, 5, 5E and 6 and 6A : 100Ω
- ISO/IEC Class C and D: 100Ω and 120Ω
- SO/ IEC Class E, 100 Ω ISO/ IEC Class F, 100Ω
-
Cat 6A/ Class EA permanent link adapters
Plug type and life: shielded and unshielded cable, TIA Cat 3, 4, 5, 5e, 6, 6A and
ISO/IEC Class C, D, E and EA permanent link
-
Cat 6A/Class EA channel adapters Plug type and life: shielded and unshielded
cable, TIA Cat 3, 4, 5, 5e, 6, 6A and ISO/IEC Class C, D, E and EA channels
|
|
Test Standards
|
- TIA Category 3, 5e, 6 per ANSI/TIA-568-C.2
- TIA Category 5 (1000BASE-T) per TIA TSB-95
- TIA Category 6 per TIA/EIA-568B.2-1
- TIA Category 6A per ANSI/TIA-568-C.2 (6A DTX-1800 only)
- TIA TSB-155 (DTX-1800 only)
- TR 24750 (DTX-1800 only)
- ISO/IEC 11801 Class C, D, and E
- ISO/IEC 11801 Class Ea, F (DTX-1800 only)
- EN 50173 Class C, D, E
- EN 50173 Class EA, F (DTX-1800 only)
- ANSI TP-PMD
- IEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T
- IEEE 802.3an 10GBASE-T
|
|
Speed of Autotest
|
Full 2-way Autotest of Category 6 Twisted-Pair links in 9 seconds
Full 2-way Autotest of Category 6A and ISO/IEC Class F links in 22 seconds
|
|
Supported Tests Parameters
|
(The selected test standard determines the test parameters and the frequency range of the tests)
Wire Map
Length
Propagation Delay
Delay Skew
DC Loop Resistance
Insertion Loss (Attenuation)
Return Loss (RL), RL @ Remote
NEXT, NEXT @ Remote
Attenuation-to-crosstalk Ratio (ACR-N), ACR-N @ Remote
ACR-F (ELFEXT), ACR-F @ Remote
Power Sum ACR-F (ELFEXT), PS ACR-F @ Remote
Power Sum NEXT, PS NEXT @ Remote
Power Sum ACR-N, PS ACR-N @ Remote
Power Sum Alien Near End Xtalk (PS ANEXT)
Power Sum Alien Attenuation Xtalk Ratio Far End (PS AACR-F)
|
|
Cable Tone Generator
|
Generates tones that can be detected by a tone probe such as a Fluke Networks IntelliTone
probe. The tones are generated on all pairs. Frequency range on all pairs. Frequency
range of tones: 440 Hz to 831 Hz
|
|
Display
|
3.7 in (9.4 cm) diagonal, 240 dots wide by 320 dots high, passive color, transmissive
LCD with backlight.
|
|
Input Protection
|
Protected against continuous telco voltages and 100 mA over-current. Occasional
ISDN over-voltages will not cause damage.
|
|
Case
|
High impact plastic with shock absorbing overmold
|
|
Dimensions
|
Main unit and Smart Remote: 8.5 in x 4.4 in x 2.4 in (21.6 cm x 11.2 cm x 6cm), nominal
|
|
Weight
|
2.4 lb (1.1 kg), nominal (without adapter or module)
|
|
Operating Temperature
|
32°F to 104°F (0°C to 40°C)
|
|
Storage Temperature
|
-4°F to 힍°F (-20°C to °C)
|
|
Operating relative humidity (% RH without condensation)
|
32°F to 95 °F (0°C to 35°C): 0 % to 90 % 95°F to 113°F (35°C to 45°C): 0 % to 70 %
|
|
Vibration
|
Random, 2 g, 5 Hz -500 Hz
|
|
Shock
|
1 m drop test with and without module and adapter attached
|
|
Safety
|
CSA C22.2 No. 1010.1: 1992 EN 61010-1 1st Edition Amendments 1, 2
|
|
Pollution degree
|
Pollution Degree 2 as defined in IEC 60664 and applied to IEC 60950 "Safety of Information
Technology Equipment, 1999"
|
|
Altitude
|
Operating: 4000 m; Storage: 12000 m
|
|
EMC
|
EN 61326-1
|
|
Power
|
- Main unit and remote: Lithium-ion battery pack, 7.4 V, 4000 mAh
- Typical battery life: 12 to 14 hours
- Charge time (with tester off): 4 hours (below 40 °C)
- AC adapter/charger, USA version: Linear power supply; Input 108 V ac to 132 V ac, 60 Hz ; Output 15 V dc, 1.2 A
-
AC adapter/charger, international version: Switching power supply; Input 90 V ac
to 264 V ac, 48 to 62 Hz; Output 15 V dc, 1.2 A (isolated output)
- Memory backup power in main unit: Lithium battery
- Typical life of lithium battery: 5 years
-
The battery will not charge at temperatures outside of 0°C to 45°C (32°F to 113°F).
The battery charges at a reduced rate between 40°C and 45°C (104°F and 113°F).
|
|
Languages Supported
|
English, French, German, Spanish, Portuguese, Italian, Japanese, and Simplified
Chinese, Traditional Chinese, Korean, Russian, Czech, Polish, Swedish, Hungarian.
|
|
Calibration
|
Service center calibration period is 1 year
|
|
Performance Specifications
|
Note: all specifications for tests on twisted-pair cabling apply to 100 Ω cable.
Contact Fluke Networks for information on measurement performance for cable with
a different impedance.
|
|
Baseline accuracy
|
The baseline accuracy of all DTX Series testers meets or exceeds the requirements
of Level IV as in IEC 61935-1/Ed. 3 over the frequency range supported by the tester.
|
|
Category 6A/Class EA link test modes (and lower link categories)
|
DTX CableAnalyzer far exceeds Level III requirements of ANSI/TIA-1152 and IEC 61935-1/Ed.3
|
|
Class F link test modes
|
DTX-1800 is meets or exceeds the requirements of Level IV as in IEC 61935-1/Ed. 3.
|
|
Length for Twisted Pair Cabling
|
(Length specs do not include the uncertainty of the cable's NVP Value)
|
|
Parameter
|
Single-ended Test
Dual-ended Test (Main and Remote)
|
|
Range
|
800 m (2600 ft) - Single-ended Test
150 m (490 ft) - Dual-ended Test (Main and Remote)
|
|
Resolution
|
0.1 m or 1 ft - Single-ended Test
0.1 m or 1 ft - Dual-ended Test (Main and Remote)
|
|
Accuracy
|
± (1m 4%) - Single-ended Test
± (1m 4%) - Dual-ended Test (Main and Remote)
|
|
Delay Skew
|
|
Parameter
|
Twisted Pair Cabling
|
|
Range
|
0 ns to 100 ns
|
|
Resolution
|
1 ns
|
|
Accuracy
|
± 10 ns
|
|
DC Loop Resistance Test
|
|
Parameter
|
Twisted Pair Cabling
|
|
Range
|
O Ω to 53Ω
|
|
Resolution
|
0.1 Ω
|
|
Accuracy
|
± (1 Ω 1%)
|
|
Overload Recovery Time
|
Less than 10 minutes to rated accuracy following over-voltage. Referencing is required
after repeated or prolonged over-voltage.
|
|
